Charge Equipment
Charge Equipment
   This series charging equipment is used for acid miner , s lamp or other same style one
The current is constant in initial and the voltage is normal charging.It also provides with
manual adjusting voitage mothed.
    The model of 6003-10J charging equipment is intelligence one.It can charge automaticly
with constant current voltage in different sections.
YLCLF102JZ(D)
YLCTF102JZ(A)
YLKTS-102B
ylkts-102g

Model

Input Voltage

Output

No. Charged

Function

Dimension

Weight

Price

MSKD-5509A

AC220V
or 110V

DC5.5V 0.9A

1PC

Universal

11x6x3.8cm

0.35kgs

5.2

CLF102JZ£¨D£©

AC380V

DC5.5V 1.1A

102PCS

Universal

210x55x173cm

300kgs

1778

CTF102K(A)

AC380V

DC5.5V 1.1A

102PCS

Not suitable for KS5LM(M) & KSW7LM(M)

223¡Á38¡Á174cm

330kgs

1156

KTS-102B

AC380V

DC5.0V 1.2A

102PCS

Universal

198.6¡Á37.5¡Á168.4cm

210kgs

1200

KTS-102G

AC380V

DC5.0V 1.2A

102PCS

Universal

218¡Á39.5¡Á168.4cm

230kgs

1200
Smal charger For K14lm & K16lm

                        it'S for KL4Lm & k16lm

                        Input: AC90-240V, 50-60Hz

                        Output: DC4.2V(+0.1V),0.9A

                        Use environment: temperature 0-40

                        degree centigrade, humidity ¡Ü 70%
